諾信電子聚合物鋰電池定制參數
來源：諾信電子?作者：諾信電子??發布時間：2020-04-21 16:36:07??閱讀數:1180
最近有客戶詢盤遇到了一些關于諾信電子聚合物鋰電池定制參數的問題，雖然我們也有專業的內部人員講解，但是由于詢盤客戶較多，大多數都是關于產品參數的問題，為了節省你的寶貴時間，今日特地整理了諾信電子聚合物鋰電池參數列表，以供大家參考。
一、農業無人機/植保機電池參數
| NXE Power Agriculture Drone Lipo | |||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (±5%g) |
最大放電倍率 | |||
|
T ±5%mm |
W ±5%mm |
L ±5%mm |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | NXE5200/25-6S | 5200 | 22.2V | 58.0 | 45.0 | 135.0 | 717.0 | 25C(130.0A) | 50C(260.0A) |
| 2 | NXE6000/25-6S | 6000 | 22.2V | 55.8 | 49.0 | 155.0 | 872.0 | 25C(150.0A) | 50C(300.0A) |
| 3 | NXE8000/25-6S | 8000 | 22.2V | 51.0 | 60.0 | 166.0 | 1143.0 | 25C(200.0A) | 50C(400.0A) |
| 4 | NXE10000/15-6S | 10000 | 22.2V | 66.0 | 60.0 | 166.0 | 1251.2 | 15C(150.0A) | 30C(300.0A) |
| 5 | NXE10000/25-6S | 10000 | 22.2V | 49.0 | 90.0 | 166.0 | 1413.0 | 25C(250.0A) | 50C(500.0A) |
| 6 | NXE13000/25-6S | 13000 | 22.2V | 68.0 | 71.0 | 181.0 | 1575.0 | 25C(325.0A) | 50C(650.0A) |
| 7 | NXE16000/25-6S | 16000 | 22.2V | 70.0 | 76.0 | 171.0 | 2002.0 | 25C(400.0A) | 50C(800.0A) |
| 8 | NXE21000/15-6S | 21000 | 22.2V | 48.5 | 97.0 | 245.0 | 2541.0 | 15C(315.0A) | 30C(630.0A) |
| 9 | NXE22000/25-6S | 22000 | 22.2V | 67.0 | 92.0 | 196.0 | 2500.0 | 25C(550.0A) | 50C(1100.0A) |
| 10 | NXE(23000/25-6S) | 23000 | 22.2V | 22.2 | 73.0 | 208.0 | 2613.0 | 25C(575.0A) | 50C(1150.0A) |
二、高倍率航模電池參數
| NXE Power High Rate Aircraft Model Lipo | |||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (±5%g) |
最大放電倍率 | |||
|
T ±5%mm |
W ±5%mm |
L ±5%mm |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | NXE1300/45-3S | 1300 | 11.1V | 20.5 | 35.0 | 72.0 | 102.0 | 45C(58.5A) | 90C(117.0A) |
| 2 | NXE1500/25-3S | 1500 | 11.1V | 26.0 | 34.0 | 72.0 | 126.0 | 25C(37.5A) | 50C(75.0A) |
| 3 | NXE1800/35-3S | 1800 | 11.1V | 21.1 | 35.0 | 103.0 | 151.5 | 35C(63.0A) | 70C(126.0A) |
| 4 | NXE2200/25-3S | 2200 | 11.1V | 22.9 | 35.0 | 103.5 | 192.0 | 25C(55.0A) | 50C(110.0A) |
| 5 | NXE2200/50-3S | 2200 | 11.1V | 25.5 | 35.0 | 104.0 | 206.0 | 50C(100.0A) | 100C(200.0A) |
| 6 | NXE2600/50-4S | 2600 | 14.8V | 21.8 | 44.0 | 134.0 | 275.2 | 50C(130.0A) | 100C(260.0A) |
| 7 | NXE3300/45-6S | 3300 | 22.2V | 44.4 | 44.0 | 135.0 | 555.0 | 45C(148.5A) | 90C(297.0A) |
| 8 | NXE4000/35-6S | 4000 | 22.2V | 39.6 | 49.0 | 155.0 | 618.0 | 35C(140.0A) | 70C(280.0A) |
| 9 | NXE4200/35-6S | 4200 | 22.2V | 50.0 | 45.0 | 135.0 | 612.0 | 35C(147.0A) | 70C(294.0A) |
| 10 | NXE1300/65-4S | 1300 | 14.8V | 30.0 | 35.0 | 72.0 | 155.0 | 65C(84.5A) | 130C(169.0A) |
| 11 | NXE1500/65-4S | 1500 | 14.8V | 28.5 | 35.0 | 90.0 | 175.0 | 65C(97.5A) | 130C(195.0A) |
| 12 | NXE2700/65-4S | 2700 | 14.8V | 26.0 | 44.0 | 138.0 | 320.0 | 65C(175.0A) | 130C(350.0A) |
| 13 | NXE3300/65-6S | 3300 | 22.2V | 48.0 | 44.0 | 138.0 | 580.0 | 65C(214.5A) | 130C(429.0A) |
| 14 | NXE4500/65-6S | 4500 | 22.2V | 49.0 | 48.0 | 158.0 | 780.0 | 65C(292.5A) | 130C(585.0A) |
| 15 | NXE5200/65-6S | 5200 | 22.2V | 55.0 | 50.0 | 160.0 | 860.0 | 65C(338.0A) | 130C(676.0A) |
三、氣槍鋰電池組參數
| NXE Power Airsoft Lipo Battery Packs Products Catalogue | |||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (±5%g) |
最大放電倍率 | |||
|
T ±5%mm |
W ±5%mm |
L ±5%mm |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | NXE1000/20-2S-1 | 1000 | 7.4V | 11.2 | 20.0 | 100.0 | 49.0 | 20C | 40C |
| 2 | NXE1000/20-3S-1 | 1000 | 11.1V | 16.3 | 20.0 | 100.0 | 67.0 | 20C | 40C |
| 3 | NXE1200/20-2S-1 | 1200 | 7.4V | 12.0 | 21.0 | 128.0 | 60.0 | 20C | 40C |
| 4 | NXE1200/20-3S-1 | 1200 | 11.1V | 17.5 | 21.0 | 128.0 | 86.0 | 20C | 40C |
| 5 | NXE1400/20-2S-1 | 1400 | 7.4V | 13.5 | 21.0 | 126.0 | 70.0 | 20C | 40C |
| 6 | NXE1400/20-3S-1 | 1400 | 11.1V | 19.4 | 21.0 | 126.0 | 102.0 | 20C | 40C |
四、FPV石墨烯電池參數
| NXE 80C+FPV Graphene Lipo Battery | |||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (±5%g) |
最大放電倍率 | |||
|
T ±5%mm |
W ±5%mm |
L ±5%mm |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | NXE1000/80-3S GR | 1000 | 11.1V | 21.0 | 35.0 | 72.0 | 115.0 | 80C(80.0A) | 160C(160.0A) |
| 2 | NXE1000/80-4S GR | 1000 | 14.8V | 27.0 | 35.0 | 72.0 | 145.0 | 80C(80.0A) | 160C(160.0A) |
| 3 | NXE1300/80-3S GR | 1300 | 11.1V | 25.5 | 35.0 | 72.0 | 135.0 | 80C(104.0A) | 160C(208.0A) |
| 4 | NXE1300/25-4S GR | 1300 | 14.8V | 33.0 | 35.0 | 72.0 | 175.0 | 80C(104.0A) | 160C(208.0A) |
| 5 | NXE1300/80-5S GR | 1300 | 18.5V | 41.0 | 35.0 | 72.0 | 212.0 | 80C(104.0A) | 160C(208.0A) |
| 6 | NXE1500/80-3S GR | 1500 | 11.1V | 29.5 | 35.0 | 72.0 | 152.0 | 80C(120.0A) | 160C(240.0A) |
| 7 | NXE1500/80-4S GR | 1500 | 14.8V | 38.0 | 35.0 | 72.0 | 192.0 | 80C(120.0A) | 160C(240.0A) |
| 8 | NXE1500/80-5S GR | 1500 | 18.5V | 48.0 | 35.0 | 72.0 | 238.0 | 80C(120.0A) | 160C(240.0A) |
五、高壓鋰電池組參數
| NXE Power High Voltage Lipo | |||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (g) |
最大放電倍率 | |||
|
T (mm) |
W (mm) |
L (mm) |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | 673496SH65-HV | 1800 | 4.35V | 6.6±0.3 | 33.5±1.0 | 96.0±1.0 | 46.2±1.5 | 65C | 130C |
| 2 | 703480SH65-HV | 1500 | 4.35V | 7.0±0.3 | 33.5±1.0 | 80.0±1.0 | 39.2±1.0 | 65C | 130C |
| 3 | 623480SH65-HV | 1300 | 4.35V | 6.0±0.3 | 33.5±1.0 | 79.0±1.0 | 34.5±1.0 | 65C | 130C |
| 4 | 603465SH65-HV | 1000 | 4.35V | 6.0±0.2 | 33.5±1.0 | 65.0±1.0 | 26.4±1.0 | 65C | 130C |
| 5 | 503465SH65-HV | 850 | 4.35V | 5.1±0.2 | 33.5±1.0 | 96.0±1.0 | 22.3±0.5 | 65C | 130C |
六、遙控車模電池參數
| NXE Power Rc Car Lipo | |||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (±5%g) |
最大放電倍率 | |||
|
T ±5%mm |
W ±5%mm |
L ±5%mm |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | NXEC3800/25-3S1P | 3800 | 11.1V | 25.0 | 46.5 | 138.0 | 298.0 | 25C(95.0A) | 50C(190.0A) |
| 2 | NXEC4000/35-2S2P | 4000 | 7.4V | 21.0 | 46.5 | 138.0 | 219.0 | 35C(140.0A) | 70C(280.0A) |
| 3 | NXEC5000/35-2S3P | 5000 | 7.4V | 25.0 | 46.5 | 69.5 | 255.0 | 35C(175.0A) | 70C(350.0A) |
| 4 | NXEC5200/45-4S2P | 5200 | 14.8V | 48.0 | 46.5 | 138.0 | 577.0 | 45C(234.0A) | 90C(468.0A) |
| 5 | NXEC5600/45-3S2P | 5600 | 11.1V | 38.0 | 46.5 | 138.0 | 458.0 | 45C(252.0A) | 90C(504.0A) |
| 6 | NXE4600/100C-2S2P | 4600 | 7.4V | 25.1 | 46.5 | 95.5 | 218.0 | 100C(460.0A) | 200C(920.0A) |
| 7 | NXEC6000/60-3S2P | 6000 | 11.1V | 38.0 | 46.5 | 138.0 | 452.0 | 60C(360.0A) | 120C(720.0A) |
| 8 | NXE5800/100C-2S2P | 5800 | 7.4V | 25.1 | 46.5 | 138.0 | 310.0 | 100C(580.0A) | 200C(1160.0A) |
| 9 | NXE6600/100C-2S2P | 6600 | 7.4V | 25.1 | 46.5 | 138.0 | 317.0 | 100C(660.0A) | 200C(1320.0A) |
| 10 | NXE7600/100C-2S2P | 7600 | 7.4V | 25.1 | 46.5 | 138.0 | 326.0 | 100C(760.0A) | 200C(1520.0A) |
七、汽車啟動電源電池參數
|
NXE Power Car Jump Starter Lipo Battery Packs (High temperature aging at 65 degree for seven days) |
|||||||||
| 項目 | 產品型號 |
標稱容量 (mAh) |
標稱電壓 (V) |
尺寸 |
重量 (±5%g) |
最大放電倍率 | |||
|
T ±5%mm |
W ±5%mm |
L ±5%mm |
持續放電倍率 | 瞬間放電倍率 | |||||
| 1 | WST386888SH45-HT | 1800 | 11.1V | 13.5 | 68.0 | 98.0 | 170.0 | 45C | 90C |
| 2 | WST406888SH45-HT | 2000 | 11.1V | 13.8 | 68.0 | 98.0 | 175.0 | 45C | 90C |
| 3 | WST605880SH35-HT | 2500 | 11.1V | 19.5 | 58.0 | 90.0 | 200.0 | 35C | 70C |
| 4 | WST5244125SH35-HT | 2600 | 11.1V | 16.5 | 44.0 | 138.0 | 206.0 | 35C | 70C |
| 5 | WST6544125SH35-HT | 3300 | 11.1V | 21.0 | 44.0 | 138.0 | 258.0 | 35C | 70C |
| 6 | WST7544125SH35-HT | 3700 | 11.1V | 24.0 | 44.0 | 138.0 | 279.0 | 35C | 70C |
| 7 | WST855880SH35-HT | 3700 | 11.1V | 27.0 | 58.0 | 90.0 | 278.0 | 35C | 70C |
| 8 | WST8044125SH35-HT | 4200 | 11.1V | 26.0 | 44.0 | 138.0 | 312.0 | 35C | 70C |
| 9 | WST9548145SH35-HT | 6000 | 11.1V | 30.5 | 48.0 | 158.0 | 446.0 | 35C | 70C |
| 10 | WST9074135SH45-HT | 9000 | 11.1V | 30.0 | 75.0 | 148.0 | 611.0 | 45C | 90C |
以上是幾個關于諾信電子比較熱門的聚合物鋰電池參數表，當然，諾信的電池遠不止這些，一一列舉出來，那可寫不完。你也可以通過點擊諾信電子官網的“產品展示”欄目了解更多聚合物鋰電池產品參數，如果有需要的鋰電池定制服務，也可以在線電聯我們，或者通過留言、郵箱等方式與我們?nèi)〉寐?lián)系，諾信電子一定會竭誠為你服務。
